FAG B7024-E-MPA-P4S-UL

FAG B7024-E-MPA-P4S-UL
FAG B7024-E-MPA-P4S-UL rulman resim 1
FAG B7024-E-MPA-P4S-UL rulman resim 2
Fiyatı: 21,459.57 ₺
Özellikler
Marka FAG
Ürün No B7024-E-MPA-P4S-UL FAG
Üretici No 0386862870000
EAN 4026677889218
Kategori Tek Sıra - Açısal Temaslı
Ağırlık ve Boyutlar
İç (d) MM 120
Dış (D) MM 180
En (B) MM 28
Ağırlık 2.06 kg
Ürün Özellikleri
Fok Kapaksız
Kasa Tipi MA - Pirinç Kafes, Dış Halkanın Ortasında
Kesinlik P4S Hassasiyet (P4ten Yüksek)
Contact Angle 25 degrees
Pairing G - Universal Pairing
Axial Internal Clearance / Preload UL - Universal design for fitting in pairs, bearing pair has slight preload in O and X arrangements
Yağlama Standart Yağlama
Data from Schaeffler (medias)
Genişlik (b) mm 28
Temel statik yük derecesi, radyal (C 0r) 78000
Limiting speed for grease lubrication (n G Grease) 6700
Limiting speed for oil lubrication (n G Oil) 10000
ECLASS number 23-05-08-03
ECLASS2 number 23-05-08-03
Suffix description
E 25° Contact Angle
MPA Window-Type Machined Brass Cage; Guidance By The Outer Ring (Housing)
P4S Boundary Dimensions ISO 4, Abec-7, Running Accuracy ISO 2, Abec-9
UL Single Bearing, Universal, Light Preload
