FAG HC7018-EDLR-T-P4S-UL

FAG HC7018-EDLR-T-P4S-UL
FAG HC7018-EDLR-T-P4S-UL rulman resim 1
FAG HC7018-EDLR-T-P4S-UL rulman resim 2
Fiyatı: 23,903.78 ₺
Özellikler
Marka FAG
Ürün No HC7018-EDLR-T-P4S-UL FAG
Üretici No 0385928190000
EAN 4026677548405
Kategori Tek Sıra - Açısal Temaslı
Ağırlık ve Boyutlar
İç (d) MM 90
Dış (D) MM 140
En (B) MM 24
İç (d) Inch 3.5433
Dış (D) Inch 5.5118
En (B) Inch 0.9449
Ağırlık 1.26 kg
Ürün Özellikleri
Fok Kapaksız
Kasa Tipi TB - Sert Fiber Kafes
Kesinlik P4S Hassasiyet (P4ten Yüksek)
Contact Angle 25 degrees
Pairing G - Universal Pairing
Axial Internal Clearance / Preload UL - Universal design for fitting in pairs, bearing pair has slight preload in O and X arrangements
Yağlama DLR
Data from Schaeffler (medias)
Genişlik (b) mm 24
Radial Static Load Rating C0r (N) 24000
Radial Dynamic Load Rating Cr (N) 34000
Temel statik yük derecesi, radyal (C 0r) "24000.0000"
Limiting speed for grease lubrication (n G Grease) 16000
Limiting speed for oil lubrication (n G Oil) 24000
ECLASS number 23-05-08-03
ECLASS2 number 23-05-08-03
Suffix description
E 25° Contact Angle
DLR Direct Lube, Integral O-Ring
T Textile Laminated Phenolic Resin, Outer Ring Guided. The Cage Is Suitable For Long-Term Operation At Temperatures Up To 100°C
P4S Boundary Dimensions ISO 4, Abec-7, Running Accuracy ISO 2, Abec-9
UL Single Bearing, Universal, Light Preload
