FAG HSS7018-C-T-P4S-UL

FAG HSS7018-C-T-P4S-UL
FAG HSS7018-C-T-P4S-UL rulman resim 1
FAG HSS7018-C-T-P4S-UL rulman resim 2
FAG HSS7018-C-T-P4S-UL rulman resim 3
FAG HSS7018-C-T-P4S-UL rulman resim 4
Fiyatı: 11,771.34 ₺
Özellikler
Marka FAG
Ürün No HSS7018-C-T-P4S-UL FAG
Üretici No 0191853830000
EAN 4012801490474
Kategori Tek Sıra - Açısal Temaslı
Ağırlık ve Boyutlar
İç (d) MM 90
Dış (D) MM 140
En (B) MM 24
İç (d) Inch 3.5433
Dış (D) Inch 5.5118
En (B) Inch 0.9449
Ağırlık 1.38 kg
Ürün Özellikleri
Fok 2RU - İki Conta / Temassız Tip
Kasa Tipi TB - Sert Fiber Kafes
Kesinlik P4S Hassasiyet (P4ten Yüksek)
Contact Angle 15 degrees
Pairing G - Universal Pairing
Axial Internal Clearance / Preload UL - Universal design for fitting in pairs, bearing pair has slight preload in O and X arrangements
Yağlama Standart Yağlama
Data from Schaeffler (medias)
Genişlik (b) mm 24
Radial Static Load Rating C0r (N) 26500
Radial Dynamic Load Rating Cr (N) 36000
Temel statik yük derecesi, radyal (C 0r) "26500.0000"
Limiting speed for grease lubrication (n G Grease) 14000
ECLASS number 23-05-08-03
ECLASS2 number 23-05-08-03
Medias description Spindle bearings HSS70..-C, adjusted, in pairs or sets, contact angle a = 15°, lip seals on both sides, non-contact, restricted tolerances
Suffix description
C 15° Or 17° Contact Angle
T Textile Laminated Phenolic Resin, Outer Ring Guided. The Cage Is Suitable For Long-Term Operation At Temperatures Up To 100°C
P4S Boundary Dimensions ISO 4, Abec-7, Running Accuracy ISO 2, Abec-9
UL Single Bearing, Universal, Light Preload
