FAG HCB7006-E-T-P4S-UL

FAG HCB7006-E-T-P4S-UL
FAG HCB7006-E-T-P4S-UL rulman resim 1
FAG HCB7006-E-T-P4S-UL rulman resim 2
FAG HCB7006-E-T-P4S-UL rulman resim 3
Fiyatı: 5,616.83 ₺
Özellikler
Marka FAG
Ürün No HCB7006-E-T-P4S-UL FAG
Üretici No 0385474300000
Alternatif Kodu 7006ACDGA/HCP4A
EAN 4026677420664
Kategori Tek Sıra - Açısal Temaslı
Ağırlık ve Boyutlar
İç (d) MM 30
Dış (D) MM 55
En (B) MM 13
İç (d) Inch 1.1811
Dış (D) Inch 2.1654
En (B) Inch 0.5118
Ağırlık 0.1 kg
Ürün Özellikleri
Fok Kapaksız
Kasa Tipi TB - Sert Fiber Kafes
Kesinlik P4S Hassasiyet (P4ten Yüksek)
Contact Angle 25 degrees
Pairing G - Universal Pairing
Axial Internal Clearance / Preload UL - Universal design for fitting in pairs, bearing pair has slight preload in O and X arrangements
Yağlama Standart Yağlama
Data from Schaeffler (medias)
Genişlik (b) mm 13
Radial Static Load Rating C0r (N) 6100
Radial Dynamic Load Rating Cr (N) 13700
Temel statik yük derecesi, radyal (C 0r) "6100.0000"
Limiting speed for grease lubrication (n G Grease) 34000
Limiting speed for oil lubrication (n G Oil) 53000
ECLASS number 23-05-08-03
ECLASS2 number 23-05-08-03
Medias description Spindle bearings HCB70..-E, adjusted, in pairs or sets, contact angle a = 25°, with ceramic balls, restricted tolerances
Suffix description
E 25° Contact Angle
T Textile Laminated Phenolic Resin, Outer Ring Guided. The Cage Is Suitable For Long-Term Operation At Temperatures Up To 100°C
P4S Boundary Dimensions ISO 4, Abec-7, Running Accuracy ISO 2, Abec-9
UL Single Bearing, Universal, Light Preload
