FAG HS7006-E-T-P4S-UL

Fiyatı: 3,210.27 ₺
Özellikler
Marka FAG
Ürün No HS7006-E-T-P4S-UL FAG
Üretici No 0191840770000
EAN 4012801491549
Kategori Tek Sıra - Açısal Temaslı
Ağırlık ve Boyutlar
İç (d) MM 30
Dış (D) MM 55
En (B) MM 13
İç (d) Inch 1.1811
Dış (D) Inch 2.1654
En (B) Inch 0.5118
Ağırlık 0.12 kg
Ürün Özellikleri
Fok Kapaksız
Kasa Tipi TB - Sert Fiber Kafes
Kesinlik P4S Hassasiyet (P4ten Yüksek)
Contact Angle 25 degrees
Pairing G - Universal Pairing
Axial Internal Clearance / Preload UL - Universal design for fitting in pairs, bearing pair has slight preload in O and X arrangements
Yağlama Standart Yağlama
Data from Schaeffler (medias)
Genişlik (b) mm 13
Radial Static Load Rating C0r (N) 4050
Radial Dynamic Load Rating Cr (N) 7800
Temel statik yük derecesi, radyal (C 0r) "4050.0000"
Limiting speed for grease lubrication (n G Grease) 34000
Limiting speed for oil lubrication (n G Oil) 53000
ECLASS number 23-05-08-03
ECLASS2 number 23-05-08-03
Suffix description
E 25° Contact Angle
T Textile Laminated Phenolic Resin, Outer Ring Guided. The Cage Is Suitable For Long-Term Operation At Temperatures Up To 100°C
P4S Boundary Dimensions ISO 4, Abec-7, Running Accuracy ISO 2, Abec-9
UL Single Bearing, Universal, Light Preload
