FAG HS7013-E-T-P4S-UL

FAG HS7013-E-T-P4S-UL
FAG HS7013-E-T-P4S-UL rulman resim 1
FAG HS7013-E-T-P4S-UL rulman resim 2
FAG HS7013-E-T-P4S-UL rulman resim 3
FAG HS7013-E-T-P4S-UL rulman resim 4
Fiyatı: 6,107.92 ₺
Özellikler
Marka FAG
Ürün No HS7013-E-T-P4S-UL FAG
Üretici No 0191842120000
EAN 4012801616652
Kategori Tek Sıra - Açısal Temaslı
Ağırlık ve Boyutlar
İç (d) MM 65
Dış (D) MM 100
En (B) MM 18
İç (d) Inch 2.5591
Dış (D) Inch 3.937
En (B) Inch 0.7087
Ağırlık 0.47 kg
Ürün Özellikleri
Fok Kapaksız
Kasa Tipi TB - Sert Fiber Kafes
Kesinlik P4S Hassasiyet (P4ten Yüksek)
Contact Angle 25 degrees
Pairing G - Universal Pairing
Axial Internal Clearance / Preload UL - Universal design for fitting in pairs, bearing pair has slight preload in O and X arrangements
Yağlama Standart Yağlama
Data from Schaeffler (medias)
Genişlik (b) mm 18
Radial Static Load Rating C0r (N) 12700
Radial Dynamic Load Rating Cr (N) 18200
Temel statik yük derecesi, radyal (C 0r) "12700.0000"
Limiting speed for grease lubrication (n G Grease) 17000
Limiting speed for oil lubrication (n G Oil) 26000
ECLASS number 23-05-08-03
ECLASS2 number 23-05-08-03
Suffix description
E 25° Contact Angle
T Textile Laminated Phenolic Resin, Outer Ring Guided. The Cage Is Suitable For Long-Term Operation At Temperatures Up To 100°C
P4S Boundary Dimensions ISO 4, Abec-7, Running Accuracy ISO 2, Abec-9
UL Single Bearing, Universal, Light Preload
