FAG XC7013-EDLR-T-P4S-UL

FAG XC7013-EDLR-T-P4S-UL
FAG XC7013-EDLR-T-P4S-UL rulman resim 1
FAG XC7013-EDLR-T-P4S-UL rulman resim 2
FAG XC7013-EDLR-T-P4S-UL rulman resim 3
FAG XC7013-EDLR-T-P4S-UL rulman resim 4
FAG XC7013-EDLR-T-P4S-UL rulman resim 5
Fiyatı: 28,608.11 ₺
Özellikler
Marka FAG
Ürün No XC7013-EDLR-T-P4S-UL FAG
Üretici No 0387805340000
EAN 4026677661289
Kategori Tek Sıra - Açısal Temaslı
Ağırlık ve Boyutlar
İç (d) MM 65
Dış (D) MM 100
En (B) MM 18
İç (d) Inch 2.5591
Dış (D) Inch 3.937
En (B) Inch 0.7087
Ağırlık 0.45 kg
Ürün Özellikleri
Fok Kapaksız
Kasa Tipi TB - Sert Fiber Kafes
Kesinlik P4S Hassasiyet (P4ten Yüksek)
Contact Angle 25 degrees
Pairing G - Universal Pairing
Axial Internal Clearance / Preload UL - Universal design for fitting in pairs, bearing pair has slight preload in O and X arrangements
Yağlama DLR
Data from Schaeffler (medias)
Genişlik (b) mm 18
Temel statik yük derecesi, radyal (C 0r) 12200
Limiting speed for grease lubrication (n G Grease) 24000
Limiting speed for oil lubrication (n G Oil) 38000
ECLASS number 23-05-08-03
ECLASS2 number 23-05-08-03
Suffix description
E 25° Contact Angle
DLR Direct Lube, Integral O-Ring
T Textile Laminated Phenolic Resin, Outer Ring Guided. The Cage Is Suitable For Long-Term Operation At Temperatures Up To 100°C
P4S Boundary Dimensions ISO 4, Abec-7, Running Accuracy ISO 2, Abec-9
UL Single Bearing, Universal, Light Preload
