FAG 20304-TVP
Fiyatı: 2,925.52 ₺
Özellikler
| Marka | FAG |
| Ürün No | 20304-TVP FAG |
| Üretici No | 0167020500000 |
| EAN | 4012801159920 |
| Kategori | Küresel Makaralı |
| İç (d) MM | 20 |
| Dış (D) MM | 52 |
| En (B) MM | 15 |
| İç (d) Inch | 0.7874 |
| Dış (D) Inch | 2.0472 |
| En (B) Inch | 0.5906 |
| Ağırlık | 0.158 kg |
| Sıkıntı | C - Silindirik Delik |
| Yağlama Enhancement | W - No Lubrication Groove or Holes |
| Fok | Kapaksız |
| Kasa Tipi | P - Plastik Kalıplı Kafes |
| Radyal İç Oyun | Cn Normal İç Oyun |
| Kesinlik | Standart Hassasiyet |
| Isı Sabitleme | Isı Stabilizasyonu Yok - 120 °Cye kadar sıcaklıklar |
| Vibrating Screen Execution | Non Vibrating Screen Execution |
| Genişlik (b) mm | 15 |
| Radial Static Load Rating C0r (N) | 24600 |
| Radial Dynamic Load Rating Cr (N) | 27000 |
| Hız sınırlaması (n G) | 11800 |
| ECLASS number | 23-05-09-12 |
| ECLASS2 number | 23-05-09-12 |
| Medias description | Barrel roller bearings 203, main dimensions to DIN 635-1 |
| TVP | Moulded Polyamide Window-Type Cage, Rolling Element Riding |
