FAG 20322-MB

FAG 20322-MB
FAG 20322-MB rulman resim 1
FAG 20322-MB rulman resim 2
FAG 20322-MB rulman resim 3
FAG 20322-MB rulman resim 4
Fiyatı: 31,638.46 ₺
Özellikler
Marka FAG
Ürün No 20322-MB FAG
Üretici No 0190143250000
EAN 4012801287135
Kategori Küresel Makaralı
Ağırlık ve Boyutlar
İç (d) MM 110
Dış (D) MM 240
En (B) MM 50
İç (d) Inch 4.3307
Dış (D) Inch 9.4488
En (B) Inch 1.9685
Ağırlık 11.5 kg
Ürün Özellikleri
Sıkıntı C - Silindirik Delik
Yağlama Enhancement W - No Lubrication Groove or Holes
Fok Kapaksız
Kasa Tipi M - Prinç Kafes
Radyal İç Oyun Cn Normal İç Oyun
Kesinlik Standart Hassasiyet
Isı Sabitleme Isı Stabilizasyonu Yok - 120 °Cye kadar sıcaklıklar
Vibrating Screen Execution Non Vibrating Screen Execution
Data from Schaeffler (medias)
Genişlik (b) mm 50
Radial Static Load Rating C0r (N) 480000
Radial Dynamic Load Rating Cr (N) 405000
Temel statik yük derecesi, radyal (C 0r) "480000.0000"
Hız sınırlaması (n G) 3000
ECLASS number 23-05-09-12
ECLASS2 number 23-05-09-12
Medias description Barrel roller bearings 203, main dimensions to DIN 635-1
Suffix description
MB Solid Brass Cage, Guidance On Inner Ring
