FAG 21322-E1-XL-TVPB

FAG 21322-E1-XL-TVPB
FAG 21322-E1-XL-TVPB rulman resim 1
FAG 21322-E1-XL-TVPB rulman resim 2
FAG 21322-E1-XL-TVPB rulman resim 3
FAG 21322-E1-XL-TVPB rulman resim 4
FAG 21322-E1-XL-TVPB rulman resim 5
Fiyatı: 8,819.20 ₺
Özellikler
Marka FAG
Ürün No 21322-E1-XL-TVPB FAG
Üretici No 0190150110000
Alternatif Kodu 21322-E1-TVPB
EAN 4026677832238
Kategori Küresel Makaralı
Ağırlık ve Boyutlar
İç (d) MM 110
Dış (D) MM 240
En (B) MM 50
İç (d) Inch 4.3307
Dış (D) Inch 9.4488
En (B) Inch 1.9685
Ağırlık 11.1 kg
Ürün Özellikleri
Sıkıntı C - Silindirik Delik
Yağlama Enhancement W33 - Lubrication Groove and 3 Holes
Fok Kapaksız
Kasa Tipi P - Plastik Kalıplı Kafes
Radyal İç Oyun Cn Normal İç Oyun
Kesinlik Standart Hassasiyet
Isı Sabitleme Isı Stabilizasyonu Yok - 120 °Cye kadar sıcaklıklar
Vibrating Screen Execution Non Vibrating Screen Execution
Data from Schaeffler (medias)
Genişlik (b) mm 50
Radial Static Load Rating C0r (N) 640000
Radial Dynamic Load Rating Cr (N) 600000
Temel statik yük derecesi, radyal (C 0r) "640000.0000"
Hız sınırlaması (n G) 4000
Referans Hızı (n u03d1r) 2700
ECLASS number 23-05-09-11
ECLASS2 number 23-05-09-11
Medias description Spherical roller bearings 213..-E1, main dimensions to DIN 635-2
Suffix description
E1 Increased Capacity Design
XL X-Life
TVPB Solid Window Cage Made From Glass Fibre Reinforced Polyamide, Guidance On Inner Ring
