FAG 21322-E1-XL-K-TVPB-C3

FAG 21322-E1-XL-K-TVPB-C3
FAG 21322-E1-XL-K-TVPB-C3 rulman resim 1
FAG 21322-E1-XL-K-TVPB-C3 rulman resim 2
FAG 21322-E1-XL-K-TVPB-C3 rulman resim 3
FAG 21322-E1-XL-K-TVPB-C3 rulman resim 4
Fiyatı: 9,799.09 ₺
Özellikler
Marka FAG
Ürün No 21322-E1-XL-K-TVPB-C3 FAG
Üretici No 0190149960030
Alternatif Kodu 21322-E1-K-TVPB-C3
EAN 4026677892164
Kategori Küresel Makaralı
Ağırlık ve Boyutlar
İç (d) MM 110
Dış (D) MM 240
En (B) MM 50
İç (d) Inch 4.3307
Dış (D) Inch 9.4488
En (B) Inch 1.9685
Ağırlık 11 kg
Ürün Özellikleri
Sıkıntı K - 1:12 Konik Delik (Çoğu Tip İçin Standart)
Yağlama Enhancement W33 - Lubrication Groove and 3 Holes
Fok Kapaksız
Kasa Tipi P - Plastik Kalıplı Kafes
Radyal İç Oyun C3 İç Oyun (Cnden Yüksek)
Kesinlik Standart Hassasiyet
Isı Sabitleme Isı Stabilizasyonu Yok - 120 °Cye kadar sıcaklıklar
Vibrating Screen Execution Non Vibrating Screen Execution
Data from Schaeffler (medias)
Genişlik (b) mm 50
Radial Static Load Rating C0r (N) 640000
Radial Dynamic Load Rating Cr (N) 600000
Temel statik yük derecesi, radyal (C 0r) "640000.0000"
Hız sınırlaması (n G) 4000
Referans Hızı (n u03d1r) 2700
ECLASS number 23-05-09-11
ECLASS2 number 23-05-09-11
Medias description Spherical roller bearings 213..-E1-K, main dimensions to DIN 635-2, with tapered bore, taper 1:12
Suffix description
E1 Increased Capacity Design
XL X-Life
K Tapered Bore, Taper 1:12
TVPB Solid Window Cage Made From Glass Fibre Reinforced Polyamide, Guidance On Inner Ring
C3 Internal Clearance Larger Than Normal
