FAG 7209-B-XL-MP

FAG 7209-B-XL-MP
FAG 7209-B-XL-MP rulman resim 1
FAG 7209-B-XL-MP rulman resim 2
FAG 7209-B-XL-MP rulman resim 3
FAG 7209-B-XL-MP rulman resim 4
Fiyatı: 1,315.60 ₺
Özellikler
Marka FAG
Ürün No 7209-B-XL-MP FAG
Üretici No 0191149070000
Alternatif Kodu 7209-B-MP
EAN 4012801326841
Kategori Tek Sıra - Açısal Temaslı
Ağırlık ve Boyutlar
İç (d) MM 45
Dış (D) MM 85
En (B) MM 19
İç (d) Inch 1.7717
Dış (D) Inch 3.3465
En (B) Inch 0.748
Ağırlık 0.43 kg
Ürün Özellikleri
Fok Kapaksız
Kasa Tipi M - Prinç Kafes
Kesinlik Standart Hassasiyet
Contact Angle 40 degrees
Pairing No pairing
Axial Internal Clearance / Preload No Preload
Yağlama Standart Yağlama
Data from Schaeffler (medias)
Genişlik (b) mm 19
Radial Static Load Rating C0r (N) 27000
Radial Dynamic Load Rating Cr (N) 40000
Temel statik yük derecesi, radyal (C 0r) "27000.0000"
Hız sınırlaması (n G) 14300
Referans Hızı (n u03d1r) 8000
ECLASS number 23-05-08-03
ECLASS2 number 23-05-08-03
Medias description Angular contact ball bearings 72..-B, main dimensions to DIN 628-1, contact angle a = 40°
Suffix description
B 40° Contact Angle
XL X-Life
MP Machined Brass Cage, Window Type, Rolling Element Riding
