FAG 7209-B-XL-TVP-UO

FAG 7209-B-XL-TVP-UO
FAG 7209-B-XL-TVP-UO rulman resim 1
FAG 7209-B-XL-TVP-UO rulman resim 2
FAG 7209-B-XL-TVP-UO rulman resim 3
FAG 7209-B-XL-TVP-UO rulman resim 4
Fiyatı: 1,391.73 ₺
Özellikler
Marka FAG
Ürün No 7209-B-XL-TVP-UO FAG
Üretici No 0167252470000
Alternatif Kodu 7209-B-TVP-UO
EAN 4012801166102
Kategori Tek Sıra - Açısal Temaslı
Ağırlık ve Boyutlar
İç (d) MM 45
Dış (D) MM 85
En (B) MM 19
İç (d) Inch 1.7717
Dış (D) Inch 3.3465
En (B) Inch 0.748
Ağırlık 0.43 kg
Ürün Özellikleri
Fok Kapaksız
Kasa Tipi P - Plastik Kalıplı Kafes
Kesinlik Standart Hassasiyet
Contact Angle 40 degrees
Pairing G - Universal Pairing
Axial Internal Clearance / Preload UO - Zero Clearance
Yağlama Standart Yağlama
Data from Schaeffler (medias)
Genişlik (b) mm 19
Radial Static Load Rating C0r (N) 27000
Radial Dynamic Load Rating Cr (N) 40000
Temel statik yük derecesi, radyal (C 0r) "27000.0000"
Hız sınırlaması (n G) 11000
Referans Hızı (n u03d1r) 8000
ECLASS number 23-05-08-03
ECLASS2 number 23-05-08-03
Medias description Angular contact ball bearing 72..-B-XL-TVP, single row
Suffix description
B 40° Contact Angle
XL X-Life
TVP Moulded Polyamide Window-Type Cage, Rolling Element Riding
UO Universal Mounting, With O And X Configurations The Bearing Pair Has Zero Clearance
