FAG 7217-B-XL-MP-UA
Fiyatı: 4,801.26 ₺
Özellikler
| Marka | FAG |
| Ürün No | 7217-B-XL-MP-UA FAG |
| Üretici No | 0191158140000 |
| Alternatif Kodu |
7217-B-MP-UA |
| EAN | 4012801282833 |
| Kategori | Tek Sıra - Açısal Temaslı |
| İç (d) MM | 85 |
| Dış (D) MM | 150 |
| En (B) MM | 28 |
| İç (d) Inch | 3.3465 |
| Dış (D) Inch | 5.9055 |
| En (B) Inch | 1.1024 |
| Ağırlık | 2.09 kg |
| Fok | Kapaksız |
| Kasa Tipi | M - Prinç Kafes |
| Kesinlik | Standart Hassasiyet |
| Contact Angle | 40 degrees |
| Pairing | G - Universal Pairing |
| Axial Internal Clearance / Preload | UA - Universal design for fitting in pairs, bearing pair has slight axial internal clearance in O and X arrangements |
| Yağlama | Standart Yağlama |
| Genişlik (b) mm | 28 |
| Radial Static Load Rating C0r (N) | 81000 |
| Radial Dynamic Load Rating Cr (N) | 93000 |
| Temel statik yük derecesi, radyal (C 0r) | "81000.0000" |
| Hız sınırlaması (n G) | 7700 |
| Referans Hızı (n u03d1r) | 4800 |
| ECLASS number | 23-05-08-03 |
| ECLASS2 number | 23-05-08-03 |
| Medias description | Angular contact ball bearings 72..-B, main dimensions to DIN 628-1, contact angle a = 40° |
| B | 40° Contact Angle |
| XL | X-Life |
| MP | Machined Brass Cage, Window Type, Rolling Element Riding |
| UA | Universal Mounting, With O And X Configurations The Bearing Pair Has Small Axial Clearance |
