FAG B7217-E-T-P4S-UM

FAG B7217-E-T-P4S-UM
FAG B7217-E-T-P4S-UM rulman resim 1
FAG B7217-E-T-P4S-UM rulman resim 2
FAG B7217-E-T-P4S-UM rulman resim 3
Fiyatı: 10,750.48 ₺
Özellikler
Marka FAG
Ürün No B7217-E-T-P4S-UM FAG
Üretici No 0388142500000
Alternatif Kodu 7217ACDGB/P4A
EAN 4026677920065
Kategori Tek Sıra - Açısal Temaslı
Ağırlık ve Boyutlar
İç (d) MM 85
Dış (D) MM 150
En (B) MM 28
İç (d) Inch 3.3465
Dış (D) Inch 5.9055
En (B) Inch 1.1024
Ağırlık 1.8 kg
Ürün Özellikleri
Fok Kapaksız
Kasa Tipi TB - Sert Fiber Kafes
Kesinlik P4S Hassasiyet (P4ten Yüksek)
Contact Angle 25 degrees
Pairing G - Universal Pairing
Axial Internal Clearance / Preload UM - Universal design for fitting in pairs, bearing pair has medium preload in O and X arrangements
Yağlama Standart Yağlama
Data from Schaeffler (medias)
Genişlik (b) mm 28
Temel statik yük derecesi, radyal (C 0r) 57000
Limiting speed for grease lubrication (n G Grease) 8000
Limiting speed for oil lubrication (n G Oil) 13000
ECLASS number 23-05-08-03
ECLASS2 number 23-05-08-03
Suffix description
E 25° Contact Angle
T Textile Laminated Phenolic Resin, Outer Ring Guided. The Cage Is Suitable For Long-Term Operation At Temperatures Up To 100°C
P4S Boundary Dimensions ISO 4, Abec-7, Running Accuracy ISO 2, Abec-9
UM Single Bearing, Universal, Medium Preload
