FAG B7217-E-T-P4S-K5-UL

FAG B7217-E-T-P4S-K5-UL
FAG B7217-E-T-P4S-K5-UL rulman resim 1
FAG B7217-E-T-P4S-K5-UL rulman resim 2
FAG B7217-E-T-P4S-K5-UL rulman resim 3
FAG B7217-E-T-P4S-K5-UL rulman resim 4
Fiyatı: 19,697.39 ₺
Özellikler
Marka FAG
Ürün No B7217-E-T-P4S-K5-UL FAG
Üretici No 0946599900000
EAN 4054372270468
Kategori Tek Sıra - Açısal Temaslı
Ağırlık ve Boyutlar
İç (d) MM 85
Dış (D) MM 150
En (B) MM 28
İç (d) Inch 3.3465
Dış (D) Inch 5.9055
En (B) Inch 1.1024
Ağırlık 1.8 kg
Ürün Özellikleri
Fok Kapaksız
Kasa Tipi TB - Sert Fiber Kafes
Kesinlik K5 - P4S + K5
Contact Angle 25 degrees
Pairing G - Universal Pairing
Axial Internal Clearance / Preload UL - Universal design for fitting in pairs, bearing pair has slight preload in O and X arrangements
Yağlama Standart Yağlama
Data from Schaeffler (medias)
Genişlik (b) mm 28
Temel statik yük derecesi, radyal (C 0r) 57000
Limiting speed for grease lubrication (n G Grease) 8000
Limiting speed for oil lubrication (n G Oil) 13000
Suffix description
E 25° Contact Angle
T Textile Laminated Phenolic Resin, Outer Ring Guided. The Cage Is Suitable For Long-Term Operation At Temperatures Up To 100°C
P4S-K5 Combination Of P4S (Boundary Dimensions ISO 4, Abec-7, Running Accuracy ISO 2, Abec-9) And K5 (Same as P4S But With Mean Sorting Of Bore And Outside Diameter)
UL Single Bearing, Universal, Light Preload
