FAG 7209-B-XL-2RS-TVP

FAG 7209-B-XL-2RS-TVP
FAG 7209-B-XL-2RS-TVP rulman resim 1
FAG 7209-B-XL-2RS-TVP rulman resim 2
FAG 7209-B-XL-2RS-TVP rulman resim 3
FAG 7209-B-XL-2RS-TVP rulman resim 4
Fiyatı: 3,147.25 ₺
Özellikler
Marka FAG
Ürün No 7209-B-XL-2RS-TVP FAG
Üretici No 0268009930000
Alternatif Kodu 7209-B-2RS-TVP
EAN 4012802123425
Kategori Tek Sıra - Açısal Temaslı
Ağırlık ve Boyutlar
İç (d) MM 45
Dış (D) MM 85
En (B) MM 19
İç (d) Inch 1.7717
Dış (D) Inch 3.3465
En (B) Inch 0.748
Ağırlık 0.42 kg
Ürün Özellikleri
Fok 2RS - İki Tarafta Kauçuk Conta
Kasa Tipi P - Plastik Kalıplı Kafes
Kesinlik Standart Hassasiyet
Contact Angle 40 degrees
Pairing No pairing
Axial Internal Clearance / Preload No Preload
Yağlama Standart Yağlama
Data from Schaeffler (medias)
Genişlik (b) mm 19
Radial Static Load Rating C0r (N) 27000
Radial Dynamic Load Rating Cr (N) 40000
Temel statik yük derecesi, radyal (C 0r) "27000.0000"
Hız sınırlaması (n G) 4550
ECLASS number 23-05-08-03
ECLASS2 number 23-05-08-03
Medias description Angular contact ball bearings 72..-B-2RS, main dimensions to DIN 628-1, contact angle a = 40°, lip seals on both sides
Suffix description
B 40° Contact Angle
XL X-Life
2RS Rubber Seals At Each Side Of The Bearing
TVP Moulded Polyamide Window-Type Cage, Rolling Element Riding
